Baby Footprint Scanner Product specification manual

Describe：

Product Introduction

Product Features

Ultra-high image quality: Optical distortion-free imaging system that captures images with high fidelity for easy extraction

Capture function is powerful: capture window size is large, support the capture of foot print, single finger, multi-finger image

fast acquisition speed: acquisition speed of at least 7 frames per second, support real-time pattern detection

Footprint and fingerprint processing algorithms: support for generating and comparing footprint and fingerprint features.

Adaptable: Applicable to various types of grain, automatically removes residual grain marks and halo effects, higher imaging quality

Durable and shock-resistant: sturdy shape, wear-resistant, shock-resistant and anti-vandalism, anti-static interference, long service life

secondary development is simple: provide Windows and Android platform SDK development kit

Product Technical Parameters

Electrical parameters
Supply Voltage		5.0V±5% USB provided
Operating Current		Typical <500mA
connector		USB2.0
ESD		Contact: ±8KV; Air: ±15KV
Environmental parameters
operating temperature		-40℃-70℃
Storage temperature		-40℃-60℃
Operating humidity		<90% R.H (non-condensing)
Storage humidity		20-93% R.H
image parameter
image resolution		500 dpi
Capture window size		150mmx150mm
Effective image size	foot print	≥139.7mm*139.7mm
	polytope	≥81.2mm*76.2mm
	single finger	≥32.5mm*32.5mm
Number of image pixels	foot print	≥2750*2750pixels
	polytope	≥1600*1500pixels
	single finger	≥640*640 pixels
Acquisition time	foot print	≥7 frames/sec (≤143ms)
	single finger	≥25 frames/sec (≤66ms)
	polytope	≥10 frames/sec (≤100ms)
image distortion		≤1%
Image background gray unevenness		≤10%
grayscale		8-bit, 256 levels
Gray-scale dynamic range		≥180 class
Image background gray value		225~255
image blemish		No more than 10 pixels with a diameter of 2 in any 600*600 area
Image center deviation		Image center deviation from the center of the acquisition window: ≤15 pixels in both X and Y directions.
Certification Standards		GA/T 866-2010 (Technical Specification for Testing of Live Fingerprint/Palmprint Acquisition Equipment) GA/T 864-2010 (Technical Specification for Live Palm Image Acquisition) GA/T 865-2010(Interface Specification for Live Palmprint Acquisition) Fingerprint Information Exchange File Format Technical Specification (Version 5.0) FBI f.test iso19794-2/ansi-378

Product appearance diagram
